Application: Technical specifications :
 Electric power consumption 4 kw
Pouch dimension L- 70- 420 mm W= 140 mm (max.) H= 80 mm (max.)
Maximum roll width 400 mm
Machine dimension L= 146 inches W= 38 inches H= 64 inches
Machine weight  1000 kg (approx.)
Motor specifications 1 Hp/ 220v single phase

Standard Features:  The machine is controlled by PLC with LCD touch screen.
High sensitive electrical-optical tracing system can be set at your request.
With special design bag former, Easily adjust packing size .
Safety protect function.
Double frequency inverter control the speed and bag length.

Optional Parts: Solid ink date code printer.
Sealing jaw with hole punching device.

TECHNICAL DATA:  Bag Size   L(10-350) x W(10-140) x H (5-55) mm
 Capacity (Bags/Min.)  40-200

 Total Power (kw)   3.0
 Film Width (mm)  Max. 430
 Machine Weight (kg)  900
 Dimension (L*W*H) (mm)  4300x1005x1750
